Projecta Digital Multimeter DT830B
Original price
$0
Original price
$29.00
-
Original price
$29.00
Original price
Current price
$29.00
$29.00
-
$29.00
Current price
$29.00
DT830B
Projecta’s entry level economical multimeter is ideal for DIY electronic applications as well as auto electrics. Featuring rotating selectable switch for easy user selectable functions. Multimeter will measure voltage, current, resistance, battery test, diode, transistor and much more.
Specifications:
Polarity: Auto Indication (-)
Voltage DC: 200mV, 2000mV, 20v, 200v, 1000v
Voltage AC: 200v and 750v (45-450hz)
Current DC: 200uA, 2000uA, 20mA, 2000mA, 10a
Resistance: 200 Ohm, 2000 Ohm 20k Ohm, 200k Ohm, 2000k Ohm
Dry Cell Battery Check: 1.5v (AA, AAA, C, D) and 9v
Diode Test: 1mA current for forward Vdrop
Transistor: hFE (0-1000) at 3.2v
Accuracy: < +/- 1.0% full scale reading
Battery: 9v dry cell
Internal Fuse: M205 (F500mA0
Low Battery Warning: 7.5v
Dimensions: 126mm x 69mm x 24mm
Weight: 115g
12 Months Warranty
